PTR-MS Trace VOC Analyzers
Extremely sensitive real-time PTR-TOF VOC and organic particle analyzers. The world's bestselling PTR-TOFMS series with TRU-E/N and patented ion-chemistry quality. Find the perfect match for your analytical challenge!
| PTR-TOF 1000 | PTR-TOF 1000 ultra | PTR-TOF 4000 | PTR-TOF 6000 | PTR-TOF 10k | |
| X2 performance option | available with X2 performance | available with X2 performance | X2 performance included | X2 performance included | |
| Main characteristics | most affordable | ultimate sensitivity | high sensitivity elevated mass resolution | high sensitivity high mass resolution | ultimate mass resolution |
| Mass resolution (m/dm) | > 1.500 | > 1.500 | > 4.000 | > 6.000 | > 10.000 |
| Sensitivity (@ m/z) 181 | > 200 cps/ppb | > 30.000 cps/ppb | > 6.000 cps/ppb | > 2.000 cps/ppb | > 1.000 cps/ppb |
| Limit of detection (@ m/z 181) | < 10 ppt (60 sec) | < 5 ppt (10 sec) | < 1 ppt (60 sec) | < 1 ppt (60 sec) | < 1 ppt (60 sec) |
